Description
Specifications –
| Digital X-Ray Source digiX-60 | Anode: W, Rh, Ag Voltage: 60 kV Power: 12 W 8 position filter changer 5 position collimator changer |
| X-Ray Detector | Type: CSA SDD Area: 40 mm2 Energy resolution: 130 eV at Mn Kα, 85 eV at Al Kα Count rate: 500 000 cps |
| Electronics | DPP: proprietary DAS (Dynamically Adaptive Shaping) type, 80 MHz sampling rate MCA: 4096 channels |
| General | Dimensions: 430 x 340 x 200 mm Weight: 18 kg Power supply: 90–240 V, 50/60 Hz Power consumption: 50 W |
| Software | Operating system: Windows XP/Vista/7/8/10 Analysis algorithms: Fundamental parameters (FPA), Empirical (regression) calibrations, Manual spectra comparison |
