Description
Technical Specification –
| Parameter | Value |
|---|---|
| Optics | LEDs, interference filters (IF) and photo sensor in transparent sample chamber. Depending on the version, up to 3 different interference filters are used. Wavelength specifications of interference filters: 430 nm Δλ = 5 nm 530 nm Δλ = 5 nm 560 nm Δλ = 5 nm 610 nm Δλ = 6 nm |
| Wavelength Accuracy | ± 1 nm |
| Photometric Range | -2600 – 2600 mAbs |
| Photometric Accuracy | 3 % FS (T = 20 °C – 25 °C) |
| Operation | Foil keypad |
| Display | backlit LCD (on keypress) |
| Suitable Vials | Round Cuvettes 24 mm |
| Calibration | Factory calibration and user calibration. Reset to factory calibration possible. |
| Interfaces | Infrared |
| Internal Storage | internal ring memory for 16 data sets |
| Power Supply | 4 batteries (AA) |
| Battery Life Time | approx. 53 hours |
| Auto – OFF | Yes |
| Clock | Real Time Clock and Date |
| Portability | Portable |
| Environmental Conditions | temperature: 5 – 40 °C rel. humidity: 30 – 90 % (non condensing) |
| Compliance | CE |
| Protection Class | IP 68 |
| Dimensions | 110 x 55 x 190 mm |
| Weight | 455 g |
